Model | QJR30-1600 | |
Axis Number | 6 | |
Payload | 30kg | |
Repeat Positioning | ±0.05mm | |
Max Armspan | 1668mm | |
Motion Range | J1 | +172° |
J2 | +147°,- 115° | |
J3 | + 83°,-98° | |
J4 | ±185° | |
J5 | ±126° | |
J6 | ±360° | |
Max Speed | J1 | 172°/s |
J2 | 177°/s | |
J3 | 189°/s | |
J4 | 429°/s | |
J5 | 412°/s | |
J6 | 429°/s | |
Allowable Torque | J4 | 83.3N·m |
J5 | 43.3N·m | |
J6 | 37.4Nm | |
Inertia Moment | J4 | 6.4kg·m² |
J5 | 7.2kg·m² | |
J6 | 2.3kg·m² | |
Robot Body Weight | 270kg | |
Power Capacity | 3.8kVA | |
Power Supply | One phase 220V ±10% | |
Cabinet Size | 600*480*920mm | |
Cabinet Weight | 95kg | |
Installing Form | Ground Mounted/ Ceiling | |
Application | Handling, assembly, sorting, loading and unloading etc. |
