ABB INDUSTRIAL ROBOTS & AUTOMATION SOLUTIONS

ABB Industrial Robots: Models and Selection Guide

Compare ABB robots for articulated, collaborative, SCARA, delta, palletizing, painting and other automation applications. Choose the robot category first, then evaluate payload, reach, mounting, protection and controller or software requirements.

129 Listed ConfigurationsIndustrial and Collaborative CategoriesRobot and Solution Review

How to shortlist an ABB robot

Start with the robot architecture and process, then compare payload and reach within that category. Mounting, protection, controller or software compatibility and the total end-of-arm load can be decisive even when basic capacity looks similar.

Choose the robot categorySeparate articulated, collaborative, SCARA, delta, palletizing and painting applications.

Size the complete payloadInclude end-of-arm tooling, the part, adapters, center of gravity and inertia.

Confirm the platformReview mounting, protection, controller, software, safety and interfaces before integration.

Configuration confirmation: ABB robot availability, exact variant, controller, options, tooling, safety, price, lead time, destination, warranty, service and compliance are confirmed for the requested configuration. The model table does not by itself define the complete automation package.

Compare ABB models

Compare ABB robot configurations

Filter by model, category, payload and reach after choosing the required robot architecture. Use mounting, protection and application details to distinguish variants, then confirm controller and software compatibility for the project.

129 configurations

Move the table horizontally

Exact selection	Category	Family	Axes	Payload	Reach	Repeatability	Protection	Mounting	Next action
IRB 1010-1.5/0.37	Small articulated robot	IRB 1010	6	1.5 kg	0.37 m	0.01 mm	Standard: IP40	Floor, inverted	Request this selection
IRB 1090-3.5/0.58	Small articulated robot	IRB 1090	6	3.5 kg	0.58 m	0.05 mm	Standard: IP40	Floor, inverted	Request this selection
IRB 1100-4/0.475	Small articulated robot	IRB 1100	6	4 kg	0.475 m	0.01 mm	Standard: IP40;optional: ISO Class 4 cleanroom, IP67	Any angle	Request this selection
IRB 1100-4/0.58	Small articulated robot	IRB 1100	6	4 kg	0.58 m	0.01 mm	Standard: IP40;optional: ISO Class 4 cleanroom, IP67	Any angle	Request this selection
IRB 1200-9/0.7 Gen 2	Small articulated robot	IRB 1200 Gen2	6	9 kg	0.7 m	0.15 mm	Standard: IP40;optional: IP67, Foundry Plus 2	Floor, wall, ceiling	Request this selection
IRB 1200-8/0.9 Gen 2	Small articulated robot	IRB 1200 Gen2	6	8 kg	0.9 m	0.011 mm	Standard: IP40;optional: IP67, Foundry Plus 2	Floor, wall, ceiling	Request this selection
IRB 1200-7/0.7 Gen 2	Small articulated robot	IRB 1200 Gen2	6	7 kg	0.7 m	0.019 mm	Standard: IP40;optional: IP67, Foundry Plus 2	Floor, wall, ceiling	Request this selection
IRB 1200-5/0.9 Gen 2	Small articulated robot	IRB 1200 Gen2	6	5 kg	0.9 m	0.011 mm	Standard: IP40;optional: IP67, Foundry Plus 2	Floor, wall, ceiling	Request this selection
IRB 1300-11/0.9	Small articulated robot	IRB 1300	6	11 kg	0.9 m	0.03 mm	Standard: IP40;optional: IP67, Foundry Plus 2, ISO Class 4 cleanroom	Any angle	Request this selection
IRB 1300-10/1.15	Small articulated robot	IRB 1300	6	10 kg	1.15 m	0.023 mm	Standard: IP40;optional: IP67, Foundry Plus 2, ISO Class 4 cleanroom	Any angle	Request this selection
IRB 1300-7/1.4	Small articulated robot	IRB 1300	6	7 kg	1.4 m	0.02 mm	Standard: IP40;optional: IP67, Foundry Plus 2, ISO Class 4 cleanroom	Any angle	Request this selection
IRB 1300-12/1.4	Small articulated robot	IRB 1300	6	12 kg	1.4 m	0.05 mm	Standard: IP40;optional: IP67, Foundry Plus 2, ISO Class 4 cleanroom	Any angle	Request this selection
IRB 1520ID-4/1.5	Medium articulated robot	IRB 1520ID	6	4 kg	1.5 m	0.05 mm	Standard: IP40	Floor, inverted	Request this selection
IRB 1600-6/1.2	Medium articulated robot	IRB 1600	6	6 kg	1.2 m	0.02 mm	Standard: IP54;optional: Foundry Plus 2	Floor, wall, inverted, tilted, shelf	Request this selection
IRB 1600-6/1.45	Medium articulated robot	IRB 1600	6	6 kg	1.45 m	0.02 mm	Standard: IP54;optional: Foundry Plus 2	Floor, wall, inverted, tilted, shelf	Request this selection
IRB 1600-10/1.2	Medium articulated robot	IRB 1600	6	10 kg	1.2 m	0.05 mm	Standard: IP54;optional: Foundry Plus 2	Floor, wall, inverted, tilted, shelf	Request this selection
IRB 1600-10/1.45	Medium articulated robot	IRB 1600	6	10 kg	1.45 m	0.05 mm	Standard: IP54;optional: Foundry Plus 2	Floor, wall, inverted, tilted, shelf	Request this selection
IRB 1660ID-4/1.55	Medium articulated robot	IRB 1660ID	6	4 kg	1.55 m	0.02 mm	Standard: IP67(axis 4: IP40)	Floor, wall, inverted, tilted	Request this selection
IRB 1660ID-6/1.55	Medium articulated robot	IRB 1660ID	6	6 kg	1.55 m	0.02 mm	Standard: IP67(axis 4: IP40)	Floor, wall, inverted, tilted	Request this selection
IRB 2600-20/1.65	Medium articulated robot	IRB 2600	6	20 kg	1.65 m	0.04 mm	Standard: IP67, IP54(axis 4);optional: Foundry Plus 2	Floor, wall, inverted, tilted, shelf	Request this selection
IRB 2600-12/1.65	Medium articulated robot	IRB 2600	6	12 kg	1.65 m	0.04 mm	Standard: IP67, IP54(axis 4);optional: Foundry Plus 2	Floor, wall, inverted, tilted, shelf	Request this selection
IRB 2600-12/1.85	Medium articulated robot	IRB 2600	6	12 kg	1.85 m	0.04 mm	Standard: IP67, IP54(axis 4);optional: Foundry Plus 2	Floor, wall, inverted, tilted, shelf	Request this selection
IRB 2600ID-15/1.85	Medium articulated robot	IRB 2600ID	6	15 kg	1.85 m	0.026 mm	Standard: IP67 (base and lower arm), IP54(upper arm)	Floor, wall, inverted, tilted, shelf	Request this selection
IRB 2600ID-8/2.00	Medium articulated robot	IRB 2600ID	6	8 kg	2.00 m	0.023 mm	Standard: IP67 (base and lower arm), IP54(upper arm)	Floor, wall, inverted, tilted, shelf	Request this selection
IRB 4400/60-1.96	Medium articulated robot	IRB 4400/4400L	6	60 kg	1.96 m	0.05 mm	Standard: IP54;optional: IP67, Foundry Plus 2	Floor	Request this selection
IRB 4400L/10-2.55	Medium articulated robot	IRB 4400/4400L	6	10 kg	2.55 m	0.05 mm	Standard: IP54;optional: IP67, Foundry Plus 2	Floor	Request this selection
IRB 4600-60/2.05	Medium articulated robot	IRB 4600	6	60 kg	2.05 m	0.05 mm	Standard: IP67;optional: Foundry Plus 2, Prime 2 for the 60 kg class, ISO Class 5 cleanroom	Floor, inverted, tilted	Request this selection
IRB 4600-45/2.05	Medium articulated robot	IRB 4600	6	45 kg	2.05 m	0.05 mm	Standard: IP67;optional: Foundry Plus 2, Prime 2 for the 60 kg class, ISO Class 5 cleanroom	Floor, inverted, tilted	Request this selection
IRB 4600-40/2.55	Medium articulated robot	IRB 4600	6	40 kg	2.55 m	0.06 mm	Standard: IP67;optional: Foundry Plus 2, Prime 2 for the 60 kg class, ISO Class 5 cleanroom	Floor, inverted, tilted	Request this selection
IRB 4600-20/2.50	Medium articulated robot	IRB 4600	6	20 kg	2.50 m	0.06 mm	Standard: IP67;optional: Foundry Plus 2, Prime 2 for the 60 kg class, ISO Class 5 cleanroom	Floor, inverted, tilted	Request this selection
IRB 5710-110/2.3	Large articulated robot	IRB 5710	6	110 kg	2.3 m	0.04 mm	Standard: IP67;optional: Foundry Plus 2	Floor, tilted, inverted	Request this selection
IRB 5710-90/2.7	Large articulated robot	IRB 5710	6	90 kg	2.7 m	0.05 mm	Standard: IP67;optional: Foundry Plus 2	Floor, tilted, inverted	Request this selection
IRB 5710-90/2.3 LID	Large articulated robot	IRB 5710	6	90 kg	2.3 m	0.04 mm	Standard: IP67;optional: Foundry Plus 2	Floor, tilted, inverted	Request this selection
IRB 5710-70/2.7 LID	Large articulated robot	IRB 5710	6	70 kg	2.7 m	0.05 mm	Standard: IP67;optional: Foundry Plus 2	Floor, tilted, inverted	Request this selection
IRB 5720-180/2.6	Large articulated robot	IRB 5720	6	180 kg	2.6 m	0.04 mm	Standard: IP67;optional: Foundry Plus 2	Floor, tilted, inverted	Request this selection
IRB 5720-125/3.0	Large articulated robot	IRB 5720	6	125 kg	3.0 m	0.05 mm	Standard: IP67;optional: Foundry Plus 2	Floor, tilted, inverted	Request this selection
IRB 5720-155/2.6 LID	Large articulated robot	IRB 5720	6	155 kg	2.6 m	0.04 mm	Standard: IP67;optional: Foundry Plus 2	Floor, tilted, inverted	Request this selection
IRB 5720-90/3.0 LID	Large articulated robot	IRB 5720	6	90 kg	3.0 m	0.05 mm	Standard: IP67;optional: Foundry Plus 2	Floor, tilted, inverted	Request this selection
IRB 6730S-270/3.1	Large articulated robot	IRB 6730S	6	270 kg	3.1 m	0.06 mm	Standard: IP67;optional: Foundry Plus 2	Shelf	Request this selection
IRB 6730S-210/3.5	Large articulated robot	IRB 6730S	6	210 kg	3.5 m	0.07 mm	Standard: IP67;optional: Foundry Plus 2	Shelf	Request this selection
IRB 6730S-150/4.0	Large articulated robot	IRB 6730S	6	150 kg	4.0 m	0.07 mm	Standard: IP67;optional: Foundry Plus 2	Shelf	Request this selection
IRB 6730S-220/3.1 LID	Large articulated robot	IRB 6730S	6	220 kg	3.1 m	0.06 mm	Standard: IP67;optional: Foundry Plus 2	Shelf	Request this selection
IRB 6730S-180/3.5 LID	Large articulated robot	IRB 6730S	6	180 kg	3.5 m	0.07 mm	Standard: IP67;optional: Foundry Plus 2	Shelf	Request this selection
IRB 6730S-130/4.0 LID	Large articulated robot	IRB 6730S	6	130 kg	4.0 m	0.07 mm	Standard: IP67;optional: Foundry Plus 2	Shelf	Request this selection
IRB 6750S-350/3.2	Large articulated robot	IRB 6750S	6	350 kg	3.2 m	0.06 mm	Standard: IP67;optional: Foundry Plus 2	Shelf	Request this selection
IRB 6750S-270/3.6	Large articulated robot	IRB 6750S	6	270 kg	3.6 m	0.08 mm	Standard: IP67;optional: Foundry Plus 2	Shelf	Request this selection
IRB 6750S-215/3.9	Large articulated robot	IRB 6750S	6	215 kg	3.9 m	0.10 mm	Standard: IP67;optional: Foundry Plus 2	Shelf	Request this selection
IRB 6750S-270/3.2 LID	Large articulated robot	IRB 6750S	6	270 kg	3.2 m	0.06 mm	Standard: IP67;optional: Foundry Plus 2	Shelf	Request this selection
IRB 6750S-220/3.6 LID	Large articulated robot	IRB 6750S	6	220 kg	3.6 m	0.08 mm	Standard: IP67;optional: Foundry Plus 2	Shelf	Request this selection
IRB 6750S-185/3.9 LID	Large articulated robot	IRB 6750S	6	185 kg	3.9 m	0.10 mm	Standard: IP67;optional: Foundry Plus 2	Shelf	Request this selection
IRB 6760-200/3.2	Large articulated robot	IRB 6760	6	200 kg	3.2 m	0.06 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6760-150/3.5	Large articulated robot	IRB 6760	6	150 kg	3.5 m	0.08 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6710-210/2.65	Large articulated robot	IRB 6710	6	210 kg	2.65 m	0.03 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6710-200/2.95	Large articulated robot	IRB 6710	6	200 kg	2.95 m	0.04 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6710-175/2.65 LID	Large articulated robot	IRB 6710	6	175 kg	2.65 m	0.03 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6710-175/2.95 LID	Large articulated robot	IRB 6710	6	175 kg	2.95 m	0.04 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6720-240/2.65	Large articulated robot	IRB 6720	6	240 kg	2.65 m	0.04 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6720-210/2.8	Large articulated robot	IRB 6720	6	210 kg	2.8 m	0.05 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6720-170/3.1	Large articulated robot	IRB 6720	6	170 kg	3.1 m	0.06 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6720-215/2.65 LID	Large articulated robot	IRB 6720	6	215 kg	2.65 m	0.04 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6720-200/2.8 LID	Large articulated robot	IRB 6720	6	200 kg	2.8 m	0.05 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6720-150/3.1 LID	Large articulated robot	IRB 6720	6	150 kg	3.1 m	0.06 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6730-270/2.7	Large articulated robot	IRB 6730	6	270 kg	2.7 m	0.04 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6730-240/2.9	Large articulated robot	IRB 6730	6	240 kg	2.9 m	0.04 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6730-210/3.1	Large articulated robot	IRB 6730	6	210 kg	3.1 m	0.07 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6730-220/2.9 LID	Large articulated robot	IRB 6730	6	220 kg	2.9 m	0.04 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6730-190/3.1 LID	Large articulated robot	IRB 6730	6	190 kg	3.1 m	0.07 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6740-310/2.8	Large articulated robot	IRB 6740	6	310 kg	2.8 m	0.04 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6740-260/3.0	Large articulated robot	IRB 6740	6	260 kg	3.0 m	0.05 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6740-240/3.2	Large articulated robot	IRB 6740	6	240 kg	3.2 m	0.06 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6740-270/2.8 LID	Large articulated robot	IRB 6740	6	270 kg	2.8 m	0.04 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6740-230/3.0 LID	Large articulated robot	IRB 6740	6	230 kg	3.0 m	0.05 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6740-220/3.2 LID	Large articulated robot	IRB 6740	6	220 kg	3.2 m	0.06 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 6790-235/2.65	Large articulated robot	IRB 6790	6	235 kg	2.65 m	0.05 mm	Standard: IP69, Foundry Prime 3	Floor	Request this selection
IRB 6790-205/2.80	Large articulated robot	IRB 6790	6	205 kg	2.80 m	0.05 mm	Standard: IP69, Foundry Prime 3	Floor	Request this selection
IRB 7710-500/2.85	Large articulated robot	IRB 7710	6	500 kg	2.85 m	0.06 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 7710-430/3.1	Large articulated robot	IRB 7710	6	430 kg	3.1 m	0.06 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 7710-360/3.3	Large articulated robot	IRB 7710	6	360 kg	3.3 m	0.10 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 7710-310/3.5	Large articulated robot	IRB 7710	6	310 kg	3.5 m	0.10 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 7710-400/2.85 LID	Large articulated robot	IRB 7710	6	400 kg	2.85 m	0.06 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 7710-390/3.1LID	Large articulated robot	IRB 7710	6	390 kg	3.1 m	0.06 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 7710-325/3.3 LID	Large articulated robot	IRB 7710	6	325 kg	3.3 m	0.10 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 7710-280/3.5 LID	Large articulated robot	IRB 7710	6	280 kg	3.5 m	0.10 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 7720-620/2.9	Large articulated robot	IRB 7720	6	620 kg	2.9 m	0.05 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 7720-530/3.1	Large articulated robot	IRB 7720	6	530 kg	3.1 m	0.05 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 7720-510/3.3	Large articulated robot	IRB 7720	6	510 kg	3.3 m	0.06 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 7720-450/3.5	Large articulated robot	IRB 7720	6	450 kg	3.5 m	0.06 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 7720-560/2.9 LID	Large articulated robot	IRB 7720	6	560 kg	2.9 m	0.05 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 7720-480/3.1 LID	Large articulated robot	IRB 7720	6	480 kg	3.1 m	0.05 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 7720-400/3.3 LID	Large articulated robot	IRB 7720	6	400 kg	3.3 m	0.06 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 7720-400/3.5 LID	Large articulated robot	IRB 7720	6	400 kg	3.5 m	0.06 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 8700-800/3.50	Large articulated robot	IRB 8700	6	800 kg	3.50 m	0.08 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
IRB 8700-550/4.20	Large articulated robot	IRB 8700	6	550 kg	4.20 m	0.05 mm	Standard: IP67;optional: Foundry Plus 2	Floor	Request this selection
CRB 15000-5/0.95	Collaborative robot	CRB 15000	6	5 kg	0.95 m	0.02 mm	Standard: GoFa 5: IP54;GoFa 10 and 12: IP67;ISO Class 4 cleanroom	Any angle	Request this selection
CRB 15000-12/1.27	Collaborative robot	CRB 15000	6	12 kg	1.27 m	0.02 mm	Standard: GoFa 5: IP54;GoFa 10 and 12: IP67;ISO Class 4 cleanroom	Any angle	Request this selection
CRB 15000-10/1.52	Collaborative robot	CRB 15000	6	10 kg	1.52 m	0.02 mm	Standard: GoFa 5: IP54;GoFa 10 and 12: IP67;ISO Class 4 cleanroom	Any angle	Request this selection
CRB 1810-10/1.52	Collaborative robot	CRB 1810	6	10 kg	1.52 m	0.03 mm	IP65;ISO Class 4 cleanroom at 50% speed, ISO Class 5 cleanroom	Any angle	Request this selection
CRB 1810-13/1.34	Collaborative robot	CRB 1810	6	13 kg	1.34 m	0.03 mm	IP65;ISO Class 4 cleanroom at 50% speed, ISO Class 5 cleanroom	Any angle	Request this selection
IRB 390-15/1300	Parallel/Delta robot	IRB 390	5	15 kg	1300 mm	0.08 mm	IP67, food-grade lubricant(FGL)	Inverted	Request this selection
IRB 390-10/1300	Parallel/Delta robot	IRB 390	4	10 kg	1300 mm	0.01 mm	IP67, food-grade lubricant(FGL)	Inverted	Request this selection
IRB 360-1/1130	Parallel/Delta robot	IRB 360	4	1 kg	1130 mm	0.09 mm	IP54, IP67, IP69K, food-grade lubricant(FGL);optional cleanroom, washdown and stainless-steel versions	Inverted	Request this selection
IRB 360-3/1130	Parallel/Delta robot	IRB 360	4	3 kg	1130 mm	0.03 mm	IP54, IP67, IP69K, food-grade lubricant(FGL);optional cleanroom, washdown and stainless-steel versions	Inverted	Request this selection
IRB 360-1/1600	Parallel/Delta robot	IRB 360	4	1 kg	1600 mm	0.06 mm	IP54, IP67, IP69K, food-grade lubricant(FGL);optional cleanroom, washdown and stainless-steel versions	Inverted	Request this selection
IRB 360-8/1130	Parallel/Delta robot	IRB 360	4	8 kg	1130 mm	0.03 mm	IP54, IP67, IP69K, food-grade lubricant(FGL);optional cleanroom, washdown and stainless-steel versions	Inverted	Request this selection
IRB 360-6/1600	Parallel/Delta robot	IRB 360	4	6 kg	1600 mm	0.05 mm	IP54, IP67, IP69K, food-grade lubricant(FGL);optional cleanroom, washdown and stainless-steel versions	Inverted	Request this selection
IRB 365-1.5/1100	Parallel/Delta robot	IRB 365	5	1.5 kg	1100 mm	0.05 mm	IP54, food-grade lubricant(FGL)	Inverted	Request this selection
IRB 365-1.5/1300	Parallel/Delta robot	IRB 365	5	1.5 kg	1300 mm	0.05 mm	IP54, food-grade lubricant(FGL)	Inverted	Request this selection
IRB 365-1.5/800	Parallel/Delta robot	IRB 365	5	1.5 kg	800 mm	0.05 mm	IP54, food-grade lubricant(FGL)	Inverted	Request this selection
IRB 910INV-3/0.35	SCARA robot	IRB 910INV	4	Selection: 3 kg;payload row: 1 kg(maximum 3 kg)	0.35 m	0.01 mm	IP3;optional: ISO Class 1 cleanroom, IP54	Inverted	Request this selection
IRB 910INV-6/0.55	SCARA robot	IRB 910INV	4	Selection: 6 kg;payload row: 3 kg(maximum 6 kg)	0.55 m	0.01 mm	IP3;optional: ISO Class 1 cleanroom, IP54	Inverted	Request this selection
IRB 920-6/0.45	SCARA robot	IRB 920/920T	4	6 kg	0.45 m	0.01 mm	IP30;optional: IP54, ISO Class 5 cleanroom	Floor	Request this selection
IRB 920-6/0.55	SCARA robot	IRB 920/920T	4	6 kg	0.55 m	0.01 mm	IP30;optional: IP54, ISO Class 5 cleanroom	Floor	Request this selection
IRB 920-6/0.65	SCARA robot	IRB 920/920T	4	6 kg	0.65 m	0.02 mm	IP30;optional: IP54, ISO Class 5 cleanroom	Floor	Request this selection
IRB 920T-6/0.45	SCARA robot	IRB 920/920T	4	6 kg	0.45 m	0.01 mm	IP30;optional: IP54, ISO Class 5 cleanroom	Floor	Request this selection
IRB 920T-6/0.55	SCARA robot	IRB 920/920T	4	6 kg	0.55 m	0.01 mm	IP30;optional: IP54, ISO Class 5 cleanroom	Floor	Request this selection
IRB 920T-6/0.65	SCARA robot	IRB 920/920T	4	6 kg	0.65 m	0.02 mm	IP30;optional: IP54, ISO Class 5 cleanroom	Floor	Request this selection
IRB 930-12/0.85	SCARA robot	IRB 930	4	12 kg	0.85 m	0.01 mm	IP30	Floor	Request this selection
IRB 930-12/1.05	SCARA robot	IRB 930	4	12 kg	1.05 m	0.01 mm	IP30	Floor	Request this selection
IRB 930-22/1.05	SCARA robot	IRB 930	4	22 kg	1.05 m	0.02 mm	IP30	Floor	Request this selection
IRB 5500-22	Paint robot	IRB 5500	6	13 kg	2.97 m	0.15 mm	IP66 Ex	Floor, wall, inverted, elevated or rotating configuration	Request this selection
IRB 5500-23	Paint robot	IRB 5500	7	13 kg	2.97 m	0.15 mm	IP66 Ex	Floor, wall, inverted, elevated or rotating configuration	Request this selection
IRB 5500-25	Paint robot	IRB 5500	7	13 kg	2.97 m	0.15 mm	IP66 Ex	Floor, wall, inverted, elevated or rotating configuration	Request this selection
IRB 5500-27	Paint robot	IRB 5500	7	13 kg	2.97 m	0.15 mm	IP66 Ex	Floor, wall, inverted, elevated or rotating configuration	Request this selection
IRB 5510 6-axis configuration	Paint robot	IRB 5510	6	13 kg	2.56 m	0.15 mm	IP66 Ex	Floor	Request this selection
IRB 460-110/2.4	Palletizing robot	IRB 460	4	110 kg	2.4 m	0.20 mm	IP67	Floor	Request this selection
IRB 660-180/3.15	Palletizing robot	IRB 660	4	180 kg	3.15 m	0.05 mm	IP67	Floor	Request this selection
IRB 660-250/3.15	Palletizing robot	IRB 660	4	250 kg	3.15 m	0.05 mm	IP67	Floor	Request this selection
IRB 760-450/3.2	Palletizing robot	IRB 760	4	450 kg	Selection: 3.2 m;working-range row: 3.18 m	0.05 mm	IP67	Floor	Request this selection
IRB 760-445/3.2	Palletizing robot	IRB 760	4	Selection: 445 kg;payload row: 450 kg	Selection: 3.2 m;working-range row: 3.18 m	0.05 mm	IP67	Floor	Request this selection

Selection note: Include end-of-arm tooling and the workpiece in payload checks, and confirm mounting, protection, controller and software for the exact configuration.

ABB robots and automation solutions FAQ

Which ABB robot categories can be compared for handling, welding, palletizing or painting?

Use the page categories to narrow the relevant articulated, collaborative, SCARA, delta, palletizing or paint robot selections, then compare payload, reach, protection and mounting for the real application. Tooling, pose and cycle requirements determine the final model.

How should ABB robot payload, reach, protection and mounting be compared?

Treat all four as connected constraints. Payload must include tooling and the workpiece; reach must cover the required TCP poses; protection must match the environment; and mounting must fit the cell structure without reducing access or service clearance.

Can EVST review an ABB robot, controller and complete automation cell together?

Yes. The project scope can include the robot and controller, tooling, process equipment, fixtures, vision, PLC and networks, safety, simulation, commissioning and service responsibilities.

What information is needed to request ABB robot price and lead time?

Provide the exact selection or application, total payload, reach and poses, mounting, protection and environment, controller and interface needs, quantity, destination and requested timing. The applicable configuration is confirmed before commercial terms are prepared.

Author: EVST Editorial Team

The EVST Editorial Team maintains this page to support robot selection and project planning. Product availability, configuration, safety validation and integration scope must be confirmed for the actual application.
